MP 6503SP A3 black and white MFP

  • Copy, print, scan, optional fax
  • Prints up to 65 ppm
  • 3.2-second first copy time
  • 8,300-sheet max input

High capacity printing meets office functionality. The MP 6503 is designed to keep up with demanding workloads, affordably.

  1. Scan it fast
    Scan up to 220 double sided images per minute.
  2. Save time
    First print ready in under 4 seconds.
  3. Thick of thin paper
    Print on stock from 52 to 300g/m2.
  4. Choose your file format
    Scan and convert paper files into editable Excel, Word or PDF documents.

Production level performance

With a paper capacity up to 8,300 sheets and fast print output, large jobs can be easily in-sourced. You can schedule files to print overnight when it’s quiet. Waiting time is minimised with the Motion Detection Sensor. Extensive paper handling options lets you quickly copy, scan, fax or print. The intuitive operation panel adds simplicity to complicated tasks. Use the Ricoh Smart Connector App for added mobile connectivity, allowing files to be printed from cloud applications like Google Drive, Dropbox and OneDrive.

Non stop productivity

Help support your BYOD office policy. The MP 6503 can connect to mobile devices via wireless LAN, avoiding print drivers and software. It’s available with the Ricoh Smart Device Connector app. Access cloud applications, so you can send files to print or fax from anywhere.


Download PDF brochure


Request a quote and empower your digital workplace with us

Whatever your business needs there’s a Ricoh specialist ready to help create the ideal solution to improve your work life. Hit the ‘Request a quote’ button, complete the form with your details and we’ll contact you within 24 hours to discuss your requirements.

  • Copy, print, scan, optional fax
  • Prints up to 65 ppm
  • 3.2-second first copy time
  • 8,300-sheet max input

Specifications

기능
Copy, print, scan, optional fax
컬러
No
HDD
320 GB
메모리 - 표준
2 GB
오퍼레이션 패널
10.1-inch tilting colour WSVGA Smart operation panel
물리적 크기 (WxDxH)-기기 본체
690 x 803 x 1,161 mm
무게 - 기기 본체
200 kg or less
표준 용지입력 용량(매수)
4,300
최대 용지입력 용량(매수)
8,300
최대 용지출력 용량(매수)
3,500
용지 입력 구성 - 표준
1,550-sheet x 2 tandem paper input tray, 2 x 550-sheet paper input trays, 100-sheet bypass tray, 220-sheet SPDF, duplex unit
최대 용지 크기
A3
미디어 무게(g/m2)
52–300
인터페이스 - 표준

Mainframe
10Base-T/100Base-Tx/1000Base-T (Gigabit Ethernet)
USB Host Type A2—2 ports
NFC tag SO14443 Type A (NFC Forum Type 2 compliant)¹

Smart Operation Panel
IEEE 802.11b/g/n (Wireless LAN)¹—2.4 GHz band only
Bluetooth 4.0¹
SD card slot— supports SDHC memory card
USB Host Type A—for USB Flash memory
USB Host Type A—for External keyboard¹
USB Host Type Mini B—for NFC card reader¹

¹—Does not support printing functions

인터페이스 - 옵션
Mainframe
IEEE 1284
IEEE 802.11a/b/g/n (Wireless LAN)
USB Device Server (additional network interface port)
네트워크 프로토콜 - 표준
TCP/IP (IPv4, IPv6)
복사 속도
65 cpm—A4 LEF
52 cpm—A4 SEF
37 cpm—A3 SEF
첫 복사 시간
3.2 seconds
복사 해상도

Read
600 x 600 dpi—8-bit

Write
1,200 x 1,200 dpi

확대 범위
25–400%, in 1% steps
확대 비율
115%, 122%, 141%, 200%, 400%
축소 비율
93%, 82%, 75%, 71%, 65%, 50%, 25%
양면 복사
Single-sided to duplex, duplex to duplex via SPDF, front and back to duplex, book to duplex
책 복사
Booklet, magazine, layout and booklet
ID카드 복사
Supported
사용자 코드
1,000 user codes, 8 digits in each code
흑백 출력 속도
65 ppm
출력 해상도
1,200 x 1,200 dpi
프린터 드라이버

Standard
PCL 5e, PCL 6, XPS

Optional
PostScript 3

Universal printer driver
PostScript 3

Note: The XPS driver can be downloaded from the Ricoh website.

양면 출력
Standard
모바일 프린팅
Yes
USB/SD에서 인쇄
Supported
스캔 속도

A4, via SPDF
Single-sided
120 ipm—200 x 200 dpi, 300 x 300 dpi

Duplex
220 ipm—black and white, 200 x 200 dpi, 300 x 300 dpi
210 ipm—colour, 300 x 300 dpi
220 ipm—colour, 200 x 200 dpi

스캔 방법

Scan to USB/SD, Scan to email, Scan to webmail, Scan to folder (SMB, FTP), Scan to URL, Scan to PDF/A, Scan to searchable PDF

Note: Optional OCR unit is required to support scanning to a searchable PDF.

컬러 스캐닝
Standard
스캔 해상도
100 x 100 dpi, 200 x 200 dpi, 300 x 300 dpi, 400 x 400 dpi, 600 x 600 dpi; default 200 x 200 dpi
스캔 to 타입

Single- and multi-page TIFF
Single-page JPEG
Single- and multi-page PDF, PDF/A
Single- and multi-page high compression PDF

스캔 to 이메일

Protocols
SMTP gateway, TCP/IP

Authentication
SMTP authentication, POP before SMTP authentication

Scan resolution
100 x 100 dpi, 200 x 200 dpi, 300 x 300 dpi, 400 x 400 dpi, 600 x 600 dpi; default 200 x 200 dpi

Scan to email file types
Single-page
TIFF, JPEG, PDF, PDF/A, high compression PDF, secure PDF, searchable PDF, digitally signed PDF

Multi-page
TIFF, PDF, PDF/A, high compression PDF, encrypted PDF, searchable PDF, digitally signed PDF

Note: Optional OCR unit is required to support scanning to a searchable PDF.

스캔 to 폴더

Protocols
SMB, FTP

Security
Client folder logon, transmission encryption of logon name and password

Resolution
100 x 100 dpi, 200 x 200 dpi, 300 x 300 dpi, 400 x 400 dpi, 600 x 600 dpi; default 200 x 200 dpi

Search for client folders
SMB—browsing directly to the designated folder
FTP—by folder name

Scan to folder file types
Single-page
TIFF, JPEG, PDF, high compression PDF, secure PDF, searchable PDF, digitally signed PDF

Multi-page
TIFF, PDF, high compression PDF, encrypted PDF, searchable PDF, digitally signed PDF

Note: Optional OCR unit is required to support scanning to a searchable PDF.

TWAIN 스캐닝

Scan mode
Standard, Photo, OCR, Filing

Scan resolution
Black and white, greyscale
100 x 100 dpi–1,200 x 1,200 dpi

Colour
100 x 100 dpi–600 x 600 dpi

팩스 타입
G3 fax, Internet fax (T.37), IP fax (T.38), LAN-Fax, Paperless fax, Direct SMTP fax
팩스 회로
PSTN/PBX
팩스 호환성
ITU-T (CCITT), G3—maximum 3 lines
팩스 모뎀 속도
2,400 bps–33.6 Kbps—G3, standard with automatic shift down
팩스 압축 방법
MH, MR, MMR, JBIG
팩스 해상도
100 x 200 dpi—8 x 3.85 lines/mm
200 x 200 dpi—8 x 7.7 lines/mm
400 x 400 dpi—8 x 15.4 lines/mm
400 x 400 dpi—16 x 15.4 lines/mm

Note: 400 x 400 dpi is supported with the optional expansion memory.
G3 팩스 전송 속도
100 x 200 dpi
2 seconds approximately—JBIG, ITU-T No. 1 chart, TTI off, memory transmission
3 seconds approximately—MMR, ITU-T No. 1 chart, TTI off, memory transmission
팩스 SAF 메모리 용량
4 MB, approximately 320 pages—standard
60 MB, approximately 4,800 pages—with optional memory
팩스 메모리 백업
1 hour
단축번호
2,000 numbers
데이터 덮어쓰기 보안 시스템(DOSS) - 표준
Yes
데이터 덮어쓰기 보안 시스템(DOSS) - 옵션
Type M19—available for customers who require their devices to comply with ISO 15408 Common Criteria certification
암호화
HDD, SSH, PDF, Secure print, WEP, WPA encryption
Address book, authentication password encryption
Encryption of data sent via Scan to email and Fax forwarding (S/MIME)
인증
802.1x wired authentication
Administrator authentication
IEEE 802.11i security (WPA2)
IPv6
Quota setting
User authentication—Windows and LDAP via Kerberos, basic, user code
WiFi Protected Setup (WPS) support
Network user authentication
Windows

PCL 5c, PCL 6, and PostScript 3
Windows Vista
Windows 7
Windows 8
Windows 8.1
Windows Server 2003
Windows Server 2003 R2
Windows Server 2008
Windows Server 2008 R2
Windows Server 2012
Windows Server 2012 R2
Windows 10

Macintosh
OS X Native v10.7 or later—PostScript 3 only
IBM
AS/400, iSeries—OS/400
표준
@Remote Embedded
Java SDK
Web Image Monitor
옵션
@Remote Connector NX
Ricoh Scan CX
FlexRelease CX
Device Software Manager
Device Manager NX
GlobalScan NX
Printer Driver Packager NX
Streamline NX
모바일 어플리케이션
Smart Device Connector
Smart Device Print&Scan
전원
220–240 V, 50/60 Hz, 10 Amps—Asia Pacific, China, Korea
110 V, 60 Hz, 14 Amps—Taiwan
소비 전력
1,900 W or less—maximum power
1,138.8 W or less—operating power, Asia Pacific
1,107.9 W or less—operating power, Taiwan
261 W or less—Ready Mode, Asia Pacific
263 W or less—Ready Mode, Taiwan
165 W or less—Low Power Mode, Asia Pacific
167 W or less—Low Power Mode, Taiwan
0.9 W or less—Energy Saver Mode (Sleep Mode), Asia Pacific
1.1 W or less—Energy Saver Mode (Sleep Mode), Taiwan
일반 전기 소비량(TEC)
4.9 kWh—Asia Pacific, China, and Korea; 5.2 kWh—Taiwan
예열시간
20 seconds or less
전력 절약 모드

60 seconds shift time—Energy Saver Mode (Sleep Mode), Low Power Mode

복구 시간

18 seconds—Energy Saver Mode (Sleep Mode); Asia Pacific, China
19 seconds—Energy Saver Mode (Sleep Mode)Taiwan

9.3 seconds—Low Power Mode; Asia Pacific, China
8.5 seconds—Low Power Mode; Taiwan

그린 라벨
Blue Angel Mark (BAM)
기타 환경 특징
Eco-friendly indicator, Auto off timer, Energy Saver Timer, Remote Power Off, Default duplex printing, Eco counter, Human detection sensor
